Diamond DA50 RG |
€ 923.000 |
Overview
| Base data | | Type: | Single Prop | | Producent: | Diamond | | Model: | DA50 RG | | Bouwjaar: | 2022 | | Registration No.: | HB-DTC | | Serial No.: | 50C.A.A.023 | | Location: | Zwitserland, Basel | | Total Time (TTAF): | 337 h | | Prijs: | € 923.000 | | Full details |
| Aanbieder |
Aeromeccanica S.A
Aeroporto Cantonale di Locarno
6596 Gordola
Zwitserland
Tel: +41-91-2103128
Fax: +41-91-7450037 |
| Contact seller |
|
|
|
Full Details
| Base data | | Type: | Single Prop | | Producent: | Diamond | | Model: | DA50 RG | | Bouwjaar: | 2022 | | Registration No.: | HB-DTC | | Serial No.: | 50C.A.A.023 | | Location: | Zwitserland, Basel | | Total Time (TTAF): | 337 h | | Prijs: | € 923.000 |
| Avionics | • Integrated Garmin G1000 NXi Glass Panel Cockpit including:
• WX500 Stormscope
• TAS 605 traffic advisory system
• Garmin GCU 476 Keypad
• Garmin Synthetic Vision Technology
• Garmin GTX 345R ADS-B In/Out Transponder
• Honeywell KN63 DME
• Garmin Flight Stream 510
• 2 ea Garmin GDU 105x 10-inch Flight Display (PFD & MFD)
• Garmin GEA 71B Airframe / Engine Interface Unit
• 2 ea Garmin GIA 64W COM/NAV/SBAS-GPS/GS/LOC
• Garmin GMA 1360 Digital Audio System
• Garmin GRS 79 Attitude Heading Reference System
• Garmin GDC 72 Digital Air Data Computer
• Garmin GMU 44 Magnetometer
• Garmin GFC 700 Automatic Flight Control System including Yaw Damper and Garmin electronic stability protection (EPS)
• Garmin GTX 335 R remote ADS-B Out Transponder
• Garmin ChartView Approach Plates (subscription required)
• ELT 406 MHz
• Digital Standby Attitude Module (MD-302 SAM) |
| Exterior | Custom Paint Scheme
Two tone metallic paint Ruby Red over Metallic Silver with Antracite vinyl accents |
| Interior | Five seats, large baggage compartments
• Diamond Premium interior – Black with red accent stitching
• Adjustable backrest for pilot and copilot (with adjustable lumbar support)
• USB Power Outlets-Pilot, Copilot, Passengers 2nd Row
• Instrument Lighting
• Overhead Cabin, Reading and Map Light
• Electrically Adjustable Rudder Pedals for Pilot/Copilot
• Middle Armrest
• Dual headset plugs (LEMO & Standard)
• Sun Visors for Pilot and Copilot |
| Opmerkingen | Private aircraft
Like New!
Ramp appeal, powerful, Spacious, Sustainable, Jet A-1 Powered
The DA50RG stands out from the crowd.
Five seats, large baggage compartments
G1000 NXi Avionics
Generous payload with full fuel. 181 kts. max cruise
• Removable Right Hand Control Stick SAFETY CONCEPT
• Composite Cabin and Safety Seats
• "FAILSAFE" Airframe and Wing Design
• Multipath Lightning Protection System
• 3-Point Safety Belts Automatic (all seats)
• Garmin ESP (Electronic Stability and Protection)
MTOW: 1999 kg (4407 Lbs)
Empty Weight: 1516 kg
Weighed by manufacturer 09/03/2023
Fuel capacity total (usable fuel): 185 lt / 148 kg - 49 US gal / 326 lbs
Cruises at 180 kn (333 km/h) and has a 750 nmi (1,389 km) range, with a fuel economy of 34 L (9 US gal) per hour.
Noise: 85.0 dB(A) according ICAO Annex 16, Vol. 1, Chapter 10 (10.4b)
Max. speed (ISA, 16,000 ft, 1,700 kg, MCP): 335 km/h TAS - 181 kts TAS
Best rate of climb: 3.96 m/s - 780 ft/min
Max. range (FL180, 45% PWR) no climb, no reserves: 1,520 km - 820 nm
Max. range incl. 30 min. reserve no climb, no reserves: 1,396 km - 754 nm
Consumption at max. range (FL180, 45% PWR): 30.2 lt/hr - 8 US gal/hr
Engine Continental CD-300 Turbocharged, FADEC Controlled • Jet-A1 Engine with 224 kW - 300 HP TOP / 270 HP MCP
TBO: 2000 hrs / 12 Years
MT Propeller MTV-12-D / 210–56 3-Blade Constant Speed Propeller
TBO: 2400 hrs / 72 Months
100 hrs inspection due at 398:24 hrs
200 hrs / Annual Inspection due 03/07/2026 at 498:24 hrs
• Air Conditioning/RACC System
• TKS De-Icing system
• Oxygen System
• Built in tablet mounts (a-coloumns)
• Professional sunshades for PAX row 2 and PAX
• Garmin GSR56 Iridium satellite link for weather & SMS
Specifications subject to verification by purchaser |
